Terraform 입문: 인프라를 코드로 관리하는 시대

# main.tf
terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 5.0"
    }
  }
  required_version = ">= 1.7.0"
}

provider "aws" {
  region = "ap-northeast-2"  # 서울 리전
}

resource "aws_instance" "web" {
  ami           = "ami-0c9c942bd7bf113a2"
  instance_type = "t3.micro"

  tags = {
    Name = "my-first-terraform-server"
  }
}

# variables.tf
variable "instance_type" {
  description = "EC2 인스턴스 타입"
  type        = string
  default     = "t3.micro"
}

variable "environment" {
  description = "환경 (dev, staging, prod)"
  type        = string

  validation {
    condition     = contains(["dev", "staging", "prod"], var.environment)
    error_message = "environment는 dev, staging, prod 중 하나여야 합니다."
  }
}

# 사용
resource "aws_instance" "web" {
  instance_type = var.instance_type
  # ...
}

# outputs.tf
output "instance_public_ip" {
  description = "EC2 인스턴스의 퍼블릭 IP"
  value       = aws_instance.web.public_ip
}

output "instance_id" {
  description = "EC2 인스턴스 ID"
  value       = aws_instance.web.id
}

# 최신 Amazon Linux 2023 AMI를 자동으로 조회
data "aws_ami" "amazon_linux" {
  most_recent = true
  owners      = ["amazon"]

  filter {
    name   = "name"
    values = ["al2023-ami-*-x86_64"]
  }
}

resource "aws_instance" "web" {
  ami           = data.aws_ami.amazon_linux.id  # 조회 결과 사용
  instance_type = var.instance_type
}

$ terraform init

Initializing the backend...
Initializing provider plugins...
- Finding hashicorp/aws versions matching "~> 5.0"...
- Installing hashicorp/aws v5.82.2...
- Installed hashicorp/aws v5.82.2 (signed by HashiCorp)

Terraform has been successfully initialized!

$ terraform plan

Terraform will perform the following actions:

  # aws_instance.web will be created
  + resource "aws_instance" "web" {
      + ami                    = "ami-0c9c942bd7bf113a2"
      + instance_type          = "t3.micro"
      + id                     = (known after apply)
      + public_ip              = (known after apply)
      + tags                   = {
          + "Name" = "my-first-terraform-server"
        }
    }

Plan: 1 to add, 0 to change, 0 to destroy.

$ terraform apply

# ... plan 결과 출력 ...

Do you want to perform these actions?
  Enter a value: yes

aws_instance.web: Creating...
aws_instance.web: Still creating... [10s elapsed]
aws_instance.web: Creation complete after 32s [id=i-0abc123def456]

Apply complete! Resources: 1 added, 0 changed, 0 destroyed.

Outputs:

instance_public_ip = "3.34.123.45"

$ terraform destroy

# 삭제될 리소스 목록 출력

Do you want to destroy all resources?
  Enter a value: yes

aws_instance.web: Destroying... [id=i-0abc123def456]
aws_instance.web: Destruction complete after 40s

Destroy complete! Resources: 1 destroyed.

{
  "version": 4,
  "terraform_version": "1.9.5",
  "resources": [
    {
      "type": "aws_instance",
      "name": "web",
      "instances": [
        {
          "attributes": {
            "id": "i-0abc123def456",
            "ami": "ami-0c9c942bd7bf113a2",
            "instance_type": "t3.micro",
            "public_ip": "3.34.123.45"
          }
        }
      ]
    }
  ]
}

# backend.tf
terraform {
  backend "s3" {
    bucket         = "my-terraform-state"
    key            = "prod/vpc/terraform.tfstate"
    region         = "ap-northeast-2"
    dynamodb_table = "terraform-locks"
    encrypt        = true
  }
}

modules/
├── vpc/
│   ├── main.tf          # VPC, 서브넷, IGW 리소스
│   ├── variables.tf     # 입력 변수 (CIDR, 서브넷 수 등)
│   └── outputs.tf       # 출력 (VPC ID, 서브넷 ID 등)
├── ec2/
│   ├── main.tf
│   ├── variables.tf
│   └── outputs.tf
└── rds/
    ├── main.tf
    ├── variables.tf
    └── outputs.tf

# 루트 main.tf
module "vpc" {
  source = "./modules/vpc"

  vpc_cidr        = "10.0.0.0/16"
  public_subnets  = ["10.0.1.0/24", "10.0.2.0/24"]
  private_subnets = ["10.0.10.0/24", "10.0.20.0/24"]
  environment     = "prod"
}

module "web_server" {
  source = "./modules/ec2"

  instance_type = "t3.medium"
  subnet_id     = module.vpc.public_subnet_ids[0]  # VPC 모듈의 출력 참조
  environment   = "prod"
}

module "database" {
  source = "./modules/rds"

  instance_class = "db.t3.medium"
  subnet_ids     = module.vpc.private_subnet_ids    # 프라이빗 서브넷에 배치
  vpc_id         = module.vpc.vpc_id
  environment    = "prod"
}

module "vpc" {
  source  = "terraform-aws-modules/vpc/aws"
  version = "5.16.0"

  name = "my-vpc"
  cidr = "10.0.0.0/16"

  azs             = ["ap-northeast-2a", "ap-northeast-2c"]
  public_subnets  = ["10.0.1.0/24", "10.0.2.0/24"]
  private_subnets = ["10.0.10.0/24", "10.0.20.0/24"]

  enable_nat_gateway = true
  single_nat_gateway = true  # 비용 절약 (dev 환경)

  tags = {
    Environment = "dev"
    Terraform   = "true"
  }
}

my-web-infra/
├── main.tf           # 메인 설정
├── variables.tf      # 변수 정의
├── outputs.tf        # 출력 정의
├── terraform.tfvars  # 변수 값 (환경별)
└── .gitignore        # tfstate, .terraform 제외

terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 5.0"
    }
  }
  required_version = ">= 1.7.0"
}

provider "aws" {
  region = var.aws_region
}

# ─── VPC ───
resource "aws_vpc" "main" {
  cidr_block           = "10.0.0.0/16"
  enable_dns_hostnames = true
  enable_dns_support   = true

  tags = { Name = "${var.project}-vpc" }
}

resource "aws_subnet" "public" {
  count                   = 2
  vpc_id                  = aws_vpc.main.id
  cidr_block              = "10.0.${count.index + 1}.0/24"
  availability_zone       = data.aws_availability_zones.available.names[count.index]
  map_public_ip_on_launch = true

  tags = { Name = "${var.project}-public-${count.index + 1}" }
}

resource "aws_subnet" "private" {
  count             = 2
  vpc_id            = aws_vpc.main.id
  cidr_block        = "10.0.${count.index + 10}.0/24"
  availability_zone = data.aws_availability_zones.available.names[count.index]

  tags = { Name = "${var.project}-private-${count.index + 1}" }
}

resource "aws_internet_gateway" "main" {
  vpc_id = aws_vpc.main.id
  tags   = { Name = "${var.project}-igw" }
}

resource "aws_route_table" "public" {
  vpc_id = aws_vpc.main.id

  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.main.id
  }

  tags = { Name = "${var.project}-public-rt" }
}

resource "aws_route_table_association" "public" {
  count          = 2
  subnet_id      = aws_subnet.public[count.index].id
  route_table_id = aws_route_table.public.id
}

data "aws_availability_zones" "available" {
  state = "available"
}

# ─── Security Groups ───
resource "aws_security_group" "alb" {
  name_prefix = "${var.project}-alb-"
  vpc_id      = aws_vpc.main.id

  ingress {
    from_port   = 80
    to_port     = 80
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

resource "aws_security_group" "web" {
  name_prefix = "${var.project}-web-"
  vpc_id      = aws_vpc.main.id

  ingress {
    from_port       = 80
    to_port         = 80
    protocol        = "tcp"
    security_groups = [aws_security_group.alb.id]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

resource "aws_security_group" "db" {
  name_prefix = "${var.project}-db-"
  vpc_id      = aws_vpc.main.id

  ingress {
    from_port       = 3306
    to_port         = 3306
    protocol        = "tcp"
    security_groups = [aws_security_group.web.id]
  }
}

# ─── EC2 ───
data "aws_ami" "amazon_linux" {
  most_recent = true
  owners      = ["amazon"]

  filter {
    name   = "name"
    values = ["al2023-ami-*-x86_64"]
  }
}

resource "aws_instance" "web" {
  ami                    = data.aws_ami.amazon_linux.id
  instance_type          = var.instance_type
  subnet_id              = aws_subnet.public[0].id
  vpc_security_group_ids = [aws_security_group.web.id]

  user_data = <<-EOF
    #!/bin/bash
    dnf install -y httpd
    systemctl enable --now httpd
    echo "<h1>Hello from Terraform!</h1>" > /var/www/html/index.html
  EOF

  tags = { Name = "${var.project}-web" }
}

# ─── RDS ───
resource "aws_db_subnet_group" "main" {
  name       = "${var.project}-db-subnet"
  subnet_ids = aws_subnet.private[*].id
}

resource "aws_db_instance" "main" {
  identifier           = "${var.project}-db"
  engine               = "mysql"
  engine_version       = "8.0"
  instance_class       = "db.t3.micro"
  allocated_storage    = 20
  db_name              = "appdb"
  username             = var.db_username
  password             = var.db_password
  db_subnet_group_name = aws_db_subnet_group.main.name
  vpc_security_group_ids = [aws_security_group.db.id]
  skip_final_snapshot  = true

  tags = { Name = "${var.project}-db" }
}

variable "aws_region" {
  description = "AWS 리전"
  type        = string
  default     = "ap-northeast-2"
}

variable "project" {
  description = "프로젝트 이름"
  type        = string
  default     = "my-web"
}

variable "instance_type" {
  description = "EC2 인스턴스 타입"
  type        = string
  default     = "t3.micro"
}

variable "db_username" {
  description = "RDS 관리자 계정명"
  type        = string
  sensitive   = true
}

variable "db_password" {
  description = "RDS 관리자 비밀번호"
  type        = string
  sensitive   = true
}

# 1. 초기화
$ terraform init

# 2. 계획 확인
$ terraform plan -var="db_username=admin" -var="db_password=MySecureP@ss123"

# Plan: 12 to add, 0 to change, 0 to destroy.
# VPC, 서브넷 4개, IGW, 라우팅 테이블, SG 3개, EC2, RDS = 12개 리소스

# 3. 적용
$ terraform apply -var="db_username=admin" -var="db_password=MySecureP@ss123"

# 4. 결과 확인
$ terraform output
# instance_public_ip = "3.34.xxx.xxx"
# rds_endpoint = "my-web-db.xxxx.ap-northeast-2.rds.amazonaws.com:3306"

# Terraform Cloud 설정
terraform {
  cloud {
    organization = "my-company"

    workspaces {
      name = "my-web-prod"
    }
  }
}
